Fuel Pressure Sensors
From tank delivery to 2 500 bar rail pressure — ratiometric output, fuel-compatible diaphragms, OE-matched ranges.
Fuel pressure sensing spans three very different jobs: tank delivery pressure at a few hundred millibar, low-pressure loop monitoring at a few bar, and common-rail pressure at 2 500 bar, where the sensor is a machined pressure port with a thin-film element.
We supply all three families, matched to the OE range and connector, with diaphragms rated for prolonged contact with diesel, petrol and ethanol blends.
Common-rail units ship with their calibration record — the ECU uses this signal to command injection quantity, and an out-of-tolerance sensor shows up as hard starting and smoke.
Representative series and where they fit
Representative series, not an exhaustive price list. Series codes are our internal naming; the connector and range cells are what a buyer actually checks first. For any OE number you fit we will return the exact SHR equivalent with its own datasheet.
| Series | Sensing element | Range | Connector | Typical fitment |
|---|---|---|---|---|
| FPS-1xx | Ceramic cell | 0 – 20 bar | 3-pin, quick-connect | Tank and low-pressure loop |
| FPS-2xx | Thin-film | 0 – 400 bar | 3-pin, OE port | High-pressure petrol DI |
| FPS-3xx | Thin-film | 0 – 2500 bar | M10 × 1 rail port | Common-rail diesel |
OE numbers in demand
Numbers harvested from current after-market demand in our categories, with the application the demand carried. This is a statement of what we cross-reference routinely — not a fitment guarantee. Send your OE number and we will confirm coverage and return the datasheet before any order is placed.
| OE number | System / family | Application | Verified |
|---|---|---|---|
| 499000-6421 | Toyota/Denso | Fuel pressure | — |
| 89458-0K051 | Toyota/Denso | Fuel pressure — Hilux | |
| 2897581 | Cummins | Fuel pressure — common rail | — |
| A099 905 26 00 | Mercedes-Benz | Fuel pressure sensor | — |
Why distributors buy from SHR
Three pressure families
Tank delivery, low-pressure loop and 2 500 bar common rail — different elements for different jobs, not one part stretched across them.
Thin-film elements rated to 2 500 bar
The rail sensor is a machined pressure port with a thin-film element; its accuracy is injection quantity.
Fuel-compatible diaphragms
Rated for prolonged contact with diesel, petrol and ethanol blends, which attack diaphragms specified for one fuel only.
Calibration record with rail units
The ECU commands injection from this signal, so every rail sensor ships with its calibration record.
Ratiometric output matched to the OE ECU
0–5 V referenced to the vehicle's own 5 V supply, per the OE pin-out.
Fitment coverage
- Common-rail diesel engines
- Direct-injection petrol
- Tank and low-pressure loop monitoring
- Truck and bus
- Fleet and remanufacturing
- EU and NA markets
