ABS Wheel Speed Sensors
Wheel-end speed & rotation detection
ABS Wheel Speed Sensors
Hall-effect and passive wheel speed sensors for ABS, ESP/ESC and traction control, built as direct OE replacements with matched tooth-count response.
Every function the stability control module makes — braking balance, steering intervention, wheel-slip threshold — is derived from the wheel speed sensors. A degraded signal does not just light a warning lamp: it degrades the vehicle's entire dynamic stability envelope. Our sensors are therefore calibrated against the specific tooth-count and gap specification of your target vehicle, not against a generic curve.
We supply the active Hall-effect variants used on virtually all vehicles built from the late 1990s onwards, together with the passive magnetoresistive units still fitted on certain platforms. Both are tested for output amplitude, phase and noise floor on a rotating rig at wheel-end speed.
Connector type, cable length, grommet and clamp are matched to the OE fitment. Send the OE number and we will return the SHR part with its measured output at 60 km/h before you place an order.
Representative series and where they fit
Representative series, not an exhaustive price list. Series codes are our internal naming; the connector and range cells are what a buyer actually checks first. For any OE number you fit we will return the exact SHR equivalent with its own datasheet.
| Series | Sensing element | Range | Connector | Typical fitment |
|---|---|---|---|---|
| ABS-3 | Hall-effect, active | 30 Hz – 20 kHz | 3-pin, B640-26 | Passenger car & van |
| ABS-2 | Passive magnetoresistive | 30 Hz – 20 kHz | 2-pin, B650-6 | Legacy platforms |
| ABS-4 | Hall-effect, truck-spec | 30 Hz – 20 kHz | 4-pin, M12 18 mm | Heavy-duty / EBS |
OE numbers in demand
Numbers harvested from current after-market demand in our categories, with the application the demand carried. This is a statement of what we cross-reference routinely — not a fitment guarantee. Send your OE number and we will confirm coverage and return the datasheet before any order is placed.
| OE number | System / family | Application | Verified |
|---|---|---|---|
| 21296829 | Volvo/Mack | Truck wheel speed | — |
| 21663562 | Volvo/Mack | Truck wheel speed | — |
| 4410328090 | Knorr-Bremse | DAF / Iveco / MAN trucks (WABCO 1 m, angled) | |
| 89546-0K240 | Toyota | Hilux wheel speed | — |
| 8980521190 | Isuzu | N-series truck | — |
Why distributors buy from SHR
Calibrated per vehicle platform
Output amplitude and phase are verified against the actual ring-gear tooth count and air gap of your target model.
Active Hall and passive variants
Three-pin Hall-effect for modern vehicles and two-pin passive magnetoresistive for legacy platforms.
IP69K sensor head
Sealed head that survives wheel-wash jetting, water traps and wheel-end corrosion.
Wide output range
From 30 Hz at low crawl speed up to 20 kHz at top speed, so the control module always has usable resolution.
OE-matched hardware
Connector, cable length, grommet and retaining clip match the original so no bracket fabrication is needed.
Fitment coverage
- Passenger car ABS / ESP / ESC
- Light commercial vehicles and vans
- Heavy-duty trucks with EBS
- Tractors and agricultural vehicles
- Commercial vehicle fleets with telematics
- Aftermarket wheel-end replacement
Send your OE numbers today
Hall-effect and passive wheel speed sensors for ABS, ESP/ESC and traction control, built as direct OE replacements with matched tooth-count response.
